swiing® | One brand. Two approaches.
swiing® ingenious parts
swiing® ingenious crankshaft "High End" C3/4 & FPM (+1 mm stroke) | Puch E50
Manufacturer: swiing® ingenious parts · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 44 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 11 mm · Thread length: 15 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Weight: 970 g · Number of gears: 1 pcs · Area of application: High End
CHF 229.90
Hot
swiing® ingenious 17 mm SRF carburetor camouflaged | Puch Maxi, Supermaxi, X30 NS / NL
Manufacturer: swiing® ingenious parts · Material: Aluminum · Camouflaged: Yes · Component group Carburetor: Carburetor complete · Area of application: Tuning · Width: 47 mm · Carburetor type: SRE · Nominal diameter: 17 mm · Height: 89 mm · Height: 109 mm · Ø Internal connection: 23 mm · Ø Inside entrance: 17 mm · Ø Output inside: 17.1 mm · Mounting type: Plug connection clamped · Ø Air filter connection: 27.5 mm · Ø fuel hose connection: 5 mm · Total length: 65 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M3.5x0.6 (standard thread) · Nozzle block: 2.2 · Nozzle size: 74 · Clamping screw torque (max.): 3 N/m · Clamping screw torque (max.): 4 N/m
CHF 119.90
swiing® ingenious resonance exhaust set Ø 28 / 70 mm | Puch Maxi, X30 Sport
Manufacturer: swiing® ingenious parts · Surface: chrome-plated · Ø outside: 70 mm · Material: Steel · Total length: 730 mm · Color: Chrome · Ø Internal connection: 28 mm · Exhaust type: Cigar · Mounting type: Screwed clamp · Flame tube attachment: Flange
CHF 119.90
swiing® ingenious 45 mm cylinder kit CH12 camouflaged | Puch
Nominal diameter: 45 mm · Manufacturer: swiing® ingenious parts · Material: Aluminum · Area of application: Tuning · Camouflaged: Yes · Surface: sandblasted · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 48 mm · Ø outlet inside: 25 mm · Number of fixing points: 4 pcs · Inlet window: 23 / 21 x 14 · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 38 mm · Ø piston pin (B): 12 mm · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Hole pattern [mm]: 44 x 44 · Decompressor: No
CHF 119.90
Innovation, Expertise und High-End Tuning
swiing® ingenious parts stand for technically advanced components based on existing series parts. Each part is analysed, revised and specifically optimised by our experts to eliminate known weak points. The focus is on improved fit, greater durability and a noticeable increase in performance when driving.
The result is not show pieces, but functional, high-end tuning components that deliver in everyday use and under load. Precise manufacturing, clean materials and practical development ensure that your moped not only feels different, but is also technically improved. swiing® ingenious parts are aimed at riders who value reliable technology and sustainable performance.
swiing® revival parts
swiing® revival wheel axle set front wheel | Piaggio SI
Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Material: Steel · Surface: galvanized (blue) · Thread type: MF11x1 (fine pitch thread) · Ø shaft: 11 mm · Total length: 160 mm · Thread length: 65 mm · Shank length: 30 mm · Ball bearing closed: No · Ø ball [inch] / [mm]: 1/4" (6.35 mm)
CHF 36.90
swiing® revival 17" rear fender set angular | Puch Maxi N
Manufacturer: GPO · Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Material: Steel · Surface: chrome-plated · Surface: polished · Color: Chrome · Wheel size: 17 " · Folding the ends: closed folded · Folding the ends: not folded · Shape of the mudguard: angular · Total length over ends: 625 mm · Scope: 940 mm · Wide mudguard profile: 82 mm · Height of mudguard profile: 35 mm · Total height from support surface to top edge: 285 mm · Mounting type: Nuts & bolts
CHF 46.90
Hot
swiing® revival ball bearing countershaft | Sachs 50/2, 50/3, 50/4, 503 2AL/2BL (A2531)
Bearing type: Deep groove ball bearing · Stock number: E15 · Ø inside: 15 mm · Ø outside: 35 mm · Inner ring width: 25.6 mm · Manufacturer: swiing® revival parts · Bearing clearance: CN (standard) · Bearing cage: Sheet steel cage ball-guided · Material: Steel · Area of application: High End · Area of application: Standard · Thread type: MF20.8x1 LH (fine/left-hand thread) · Width: 8 mm · Pony OEM number: A2531 · Sachs OEM no.: 0286 079 105
CHF 49.90
swiing® revival lamp holder without brackets Inox | Piaggio Ciao PX / C24
Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Wide intake: 101 mm · Thread size: M6 · Mounting type: Screws · Number of fixing points: 3 pcs · Piaggio OEM number: 247947
CHF 24.90
Revived original parts of the highest quality
With swiing® revival parts, we make original spare parts available again that are now difficult or impossible to find. The aim is to keep classic mopeds roadworthy and preserve their original character. The form, function and appearance are consistently based on the original.
Each Revival Part is newly manufactured and carefully tested. High-quality materials and precise workmanship ensure that the parts not only look original, but also meet the demands of everyday riding today. Where appropriate, subtle technical improvements are incorporated without changing the appearance. The result is spare parts that do justice to the original and impress in the long term.
GPO tuning set 45 mm (Metrakit replica) | Puch E50
Nominal diameter: 45 mm · Manufacturer: GPO · Material: Aluminum · Material: Gray cast iron · Material: Steel · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 47.8 mm · Outlet type: straight · Hole pattern [mm]: 44 x 44 · Decompressor: No · Camouflaged: No · Area of application: Racing · Area of application: Tuning
CHF 399.00
Not in stock
GPO clutch facings mono with reinforced springs & starter bell | Piaggio Ciao, SI, Bravo, Boxer
Manufacturer: GPO · Material: Aluminum · Material: Composite materials · Material: Spring steel · Material: Steel · Surface: varnished · Recording type: 2-edge · Number of jaws: 3 pcs · Number of springs: 6 pcs · Area of application: Tuning · Piaggio OEM number: 104480 · Piaggio OEM number: 114943 · Alternative version of the Piaggio OEM number: 121753
CHF 42.90
New
Hot
43.5 mm cylinder head CNC Tuning | Puch E50
Manufacturer: Made in Switzerland · Material: Aluminum · Ø cylinder: 43.5 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 44 x 44 · Candle thread: short · Decompressor: No · Total length: 169 mm · Width: 164 mm · Height: 50.6 mm · Area of application: Tuning
CHF 189.90
Not in stock
GPO clutch facings mono with reinforced springs | Piaggio Ciao, SI, Bravo, Boxer
Manufacturer: GPO · Material: Aluminum · Material: Composite materials · Material: Spring steel · Surface: varnished · Number of jaws: 3 pcs · Number of springs: 6 pcs · Thickness: 14 mm · Area of application: Tuning · Piaggio OEM number: 104480 · Alternative version of the Piaggio OEM number: 121753
CHF 33.90
Starter shaft with drive pinion (pedal) original | Tomos Standard, Flexer, Youngster
Manufacturer: Tomos · Material: Steel · Ø Shaft: 15.8 mm · Number of teeth: 25 pcs · Total length: 245 mm · Tomos OEM number: 032073 · Tomos OEM number: 217584 · Tomos OEM number: 223448 · Tomos OEM number: 1232658
CHF 129.90
swiing® revival repair kit main stand | Piaggio Bravo, SUPERbravo
Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Material: Spring steel · Material: Steel · Surface: galvanized (blue) · Surface: stainless · Total length: 112 mm · Width: 14 mm · Mounting type: Circlip · Number of fixing points: 2 pcs · Piaggio OEM number: 214490 · Piaggio OEM number: 226667 · Piaggio OEM number: 226668
CHF 16.90
swiing® ingenious air filter insert "Racing" | Sachs 503 AB / ABL, 504, 505
Manufacturer: swiing® ingenious parts · Color: black · Color: yellow · Material: Paper · Material: Rubber · Total length: 58 mm · Width: 58 mm · Height: 65 mm · Ø inside: 27 mm · Ø outside: 50 mm · Mounting type: inserted · Area of application: Racing · Area of application: Tuning · Alternative version of the Pony OEM number: A4336 · Alternative version of the Sachs OEM number: 0225 010 100
CHF 11.90
