swiing® revival engine seal | Puch Velux X30

swiing® revival plain bearing clutch basket | Puch Z50

Nominal diameter: 15 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze · Ø outside: 17 mm · Ø inside: 15 mm · Total height: 16.2 mm

NSK L17 shoulder ball bearing

Material: Brass · Material: Steel · Surface: blank / oiled · Bearing cage: Brass cage ball-guided · Stock number: L17 · Width: 10 mm · Inner ring width: 10 mm · Manufacturer: NSK · Ø outside: 40 mm · Bearing clearance: CN (standard) · Bearing type: Shoulder bearing · Area of application: Standard · Ø inside: 17 mm · Ball bearing closed: No

Oil seal NBR 17/35/7 A DUO

Material: NBR · Surface: rubberized · Simmering type: A DUO - With rubberized outer casing / two sealing lips. · Width: 7 mm · Ø outside: 35 mm · Ø inside: 17 mm · Temperature resistance (min.): -30 - 100 °C

Oil seal NBR 17/28/7 AS Pinion shaft | Puch Z50

Material: NBR · Surface: rubberized · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Width: 7 mm · Manufacturer: Puch · Ø outside: 28 mm · Place of use: Pinion shaft · Area of application: Standard · Ø inside: 17 mm · Temperature resistance (min.): -30 - 100 °C

swiing® revival gearbox cover gasket | Puch Velux X30

Material: Sealing paper · Thickness: 0.4 mm · Manufacturer: swiing® revival parts · Number of fixing points: 7 pcs · Number of components: 1 pcs

swiing® revival bearings & oil seals | Puch Z50

Material: Plastic · Material: Steel · Manufacturer: NTN · Manufacturer: SKF · Manufacturer: swiing® revival parts · Number of components: 6 pcs · Area of application: Standard

NSK L17 shoulder ball bearing 17/40/10 engine | Puch Z50, ZA50

Stock number: L17 · Width: 10 mm · Manufacturer: NSK · Ø outside: 40 mm · Bearing type: Shoulder bearing · Ø inside: 17 mm

swiing® revival shim set crankshaft L17 | Puch Z50

Material: Steel · Surface: blank / oiled · Nominal diameter: 17 mm · Thickness: 0.1 mm · Thickness: 0.15 mm · Thickness: 0.2 mm · Thickness: 0.25 mm · Thickness: 0.3 mm · Manufacturer: swiing® revival parts · Ø outside: 23.8 mm · Ø inside: 17.1 mm

swiing crankshaft | High End Puch X30 Velux (Z50)

Material: Aluminum · Material: Steel · Manufacturer: swiing · Weight: 954 g · Cheek type: Full cheeks · Crankshaft stroke: 43 mm · Connecting rod length center-center: 90 mm · Number of gears: 2 pcs · Total length of crankpin on clutch side: 58 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 70 mm · Area of application: High End · Area of application: Racing · Area of application: Tuning · Ø Connecting rod eye: 15 mm · Ø piston pin (B): 12 mm · Ø Bearing seat (clutch side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Ø Bearing seat (ignition side): 17 mm · Thread length: 8 mm · Thread length: 13 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Length 1st paragraph: 20.3 mm · Length 2nd paragraph: 19 mm · Ø 1st step (on the coupling side): 17 mm · Ø 2nd shoulder (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm

Oil seal NBR 17/35/7 A DUO crankshaft | Puch Z50, ZA50

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: A DUO - With rubberized outer casing / two sealing lips. · Ø inside: 17 mm · Ø outside: 35 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized
