Olympia bottom bracket bushing & pedal axle spacer tube | Piaggio Boxer

GPO pedal cranks chrome 148 mm pair

Manufacturer: GPO · Material: Steel · Color: Chrome · Surface: chrome-plated · Crank length (center-center): 120 mm · Thread type: FG14.3 (9/16" 20G) · Ø Pedal wedge: 9 mm · Cranking (offset): 30 mm · Total length: 148 mm

GPO pedal cranks chrome 153 mm strong cranked

Manufacturer: GPO · Material: Steel · Color: Chrome · Surface: chrome-plated · Crank length (center-center): 123 mm · Thread type: FG14.3 (9/16" 20G) · Ø Pedal wedge: 9.5 mm · Ø Pedal axle: 16 mm · Cranking (offset): 40 mm · Total length: 153 mm

swiing® revival Ø 9.5 mm wedge 4.5° pedal crank galvanized

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Color: silver · Angle crank wedge: 4.5° · Ø outside: 9.5 mm · Thread type: M7x1 (standard thread) · Total length: 43 mm

swiing® revival Ø 9.5 mm wedge 3.5° crank handle Inox

Manufacturer: swiing® revival parts · Material: Chrome steel (known as Nirosta®) · Angle crank wedge: 3.5° · Ø outside: 9.5 mm · Thread type: M7x1 (standard thread) · Total length: 44 mm

GPO pedal axle 28 teeth keyway galvanized (1A quality) | Piaggio Ciao

Chain pitch: 1/2" x 1/8" · Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Color: silver · Total length: 234 mm · Number of teeth: 28 pcs · Ø outside: 130 mm · Wavelength from wreath: 48 mm · Wavelength from wreath: 183 mm · Ø Outer sprocket: 118 mm · Ø Pedal arm holder: 16 mm · Crank (wreath): 2.3 mm · Piaggio OEM number: 813424

GPO pedal axle 23 teeth with keyway | Piaggio SI

Chain pitch: 1/2" x 3/16" · Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Color: Chrome · Total length: 257 mm · Number of teeth: 23 pcs · Wavelength from wreath: 60 mm · Wavelength from wreath: 194 mm · Ø Outer sprocket: 100 mm · Ø Pedal arm holder: 16 mm · Ø Bearing support: 15.9 mm · Crank (wreath): 2 mm

KMC Standard pedal chain

Chain pitch: 1/2" x 1/8" · Chain type: 410 · Manufacturer: KMC · Material: Steel · Rolling circumference: 1422 mm · Surface: blank / oiled · Color: gray · Number of chain links: 112 pcs · Chain lock type: Spring lock

Magura cable holder

Manufacturer: Magura · Material: Brass · Surface: nickel-plated · Color: silver · Ø Cable bushing: 4 mm · Ø outside: 8 mm · Ø Nipple hole: 6.2 mm · Ø Bundle: 10 mm · Total length: 14.5 mm · Area of application: Standard

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Filter type: Plastic net · Mounting type: Union nut · Installation direction: horizontal / horizontal · Thread type: MF12x1 (fine pitch thread) · Outlet direction: below · Spare tube shape: curved · Ø fuel hose connection: 6 mm · Reserve level: 70 mm

Dell'Orto 16/16 SHA carburetor hand choke

Manufacturer: Dell'Orto · Total length: 82 mm · Width: 72 mm · Material: Aluminum · Camouflaged: No · Component group Carburetor: Carburetor complete · Area of application: Tuning · Color: black · Carburetor type: SHA · Nominal diameter: 16 mm · Height: 111 mm · Ø without reducing sleeve: 21 mm · Ø Inside entrance: 16 mm · Ø Output inside: 16 mm · Ø Air filter connection: 56 mm · Ø Air filter connection: 58.5 mm · Ø Internal connection: 19 mm · Ø fuel hose connection: 5.1 mm · Ø fuel hose connection: 6 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5x0.8 (standard thread) · Mounting type: Plug connection clamped · Nozzle size: 82

Side stand chrome | Puch

Manufacturer: Made in Portugal · Material: Steel · Color: Chrome · Adjustable: Yes · Color: black · Surface: chrome-plated · Surface: powder-coated · Length pivot point - floor: 220 mm · Mounting type: Screwed clamp · Total length: 345 mm · Number of fixing points: 2 pcs

swiing® revival speedometer disk (instead of speedometer drive) Inox

Manufacturer: swiing® revival parts · Color: Chrome · Material: Chrome steel (known as Nirosta®) · Ø mounting hole: 12 mm · Ø axle: 12 mm · Ø outside: 47 mm · Total height: 12 mm

Petrol hose Ø 5 / 8 mm green 30 cm

Ø inside: 5 mm · Ø outside: 8 mm · Total length: 300 mm · Material: Plastic · Color: green

Exhaust 22 mm 2-piece replica (with number) | Puch

Manufacturer: Made in Portugal · Material: Steel · Color: Chrome · Surface: chrome-plated · Mounting type: Stud bolts & nuts · Mounting type: Welded lug · Flame tube attachment: Flange · Ø outside: 58 mm · Total length: 920 mm · Number of fixing points: 4 pcs · Ø Flame tube outside: 22 mm · Exhaust type: Flute

Union pedals plastic standard

Drive: Hexagon socket · Drive: Outer edge · Manufacturer: Union · Material: Plastic · Material: Steel · Color: black · Width across flats SW: 15 mm · Surface: rubberized · Thread type: FG14.3 (9/16" 20G) · Total length: 129 mm · Height: 29 mm · Width: 77 mm · Reflectors: Yes

Handlebar with stem 26 cm | Piaggio Boxer

Manufacturer: Made in Italy · Material: Steel · Surface: chrome-plated · Color: Chrome · Width: 600 mm · Ø outside: 22 mm · Height: 260 mm · Ø Stem: 22 mm · Stem height: 160 mm · Mounting type: Front boom mounting · Length handlebar ends: 170 mm · Crossbar: No
